This tutorial will explain how to flash a single file or to a single partition on a Qualcomm Android device using Miracle box. While we already have a guide on flashing Qualcomm using Miracle box and another on using QFIL, this guide will come in handy when the goal is to flash to a single partition, not the full firmware.
Requirements
- Download Miracle box
- Install Qualcomm USB drivers
- Boot the Qualcomm device into EDL Mode
- The single file you intend to flash (this guide will be using recovery.img as example)
Steps to flash to single partitions on Qualcomm using Miracle box
Follow the steps below to flash single files or to single partitions on Qualcomm Android using Miracle box
See the video below or @ https://youtu.be/20VxeiSyDbo- Launch Miracle box and click the Qualcomm tab
![[Image: How-to-use-Miracle-Box-to-flash-a-single...comm-1.jpg]](https://www.hovatek.com/blog/bpyeki/uploads/2018/12/How-to-use-Miracle-Box-to-flash-a-single-partition-to-Qualcomm-1.jpg)
- Click the Flashing tab
![[Image: How-to-use-Miracle-Box-to-flash-a-single...comm-3.jpg]](https://www.hovatek.com/blog/bpyeki/uploads/2018/12/How-to-use-Miracle-Box-to-flash-a-single-partition-to-Qualcomm-3.jpg)
- Click the Custom Flasher tab
![[Image: How-to-use-Miracle-Box-to-flash-a-single...comm-4.jpg]](https://www.hovatek.com/blog/bpyeki/uploads/2018/12/How-to-use-Miracle-Box-to-flash-a-single-partition-to-Qualcomm-4.jpg)
- Connect the Device to PC (via USB cord) while in Emergency Download (EDL) mode then click Port. It should get detected as Qualcomm HS-USB QDLoader 9008
![[Image: How-to-use-Miracle-Box-to-flash-a-single...comm-5.jpg]](https://www.hovatek.com/blog/bpyeki/uploads/2018/12/How-to-use-Miracle-Box-to-flash-a-single-partition-to-Qualcomm-5.jpg)
- Click the browse icon in front of File to Write
![[Image: How-to-use-Miracle-Box-to-flash-a-single...comm-6.jpg]](https://www.hovatek.com/blog/bpyeki/uploads/2018/12/How-to-use-Miracle-Box-to-flash-a-single-partition-to-Qualcomm-6.jpg)
- Navigate to and highlight the file you wish to flash then click Open
![[Image: How-to-use-Miracle-Box-to-flash-a-single...comm-7.jpg]](https://www.hovatek.com/blog/bpyeki/uploads/2018/12/How-to-use-Miracle-Box-to-flash-a-single-partition-to-Qualcomm-7.jpg)
- Select the partition under the Select Partition dropdown
![[Image: How-to-use-Miracle-Box-to-flash-a-single...comm-8.jpg]](https://www.hovatek.com/blog/bpyeki/uploads/2018/12/How-to-use-Miracle-Box-to-flash-a-single-partition-to-Qualcomm-8.jpg)
- Tick Write Partition
![[Image: How-to-use-Miracle-Box-to-flash-a-single...comm-9.jpg]](https://www.hovatek.com/blog/bpyeki/uploads/2018/12/How-to-use-Miracle-Box-to-flash-a-single-partition-to-Qualcomm-9.jpg)
- Click Start Button
![[Image: How-to-use-Miracle-Box-to-flash-a-single...omm-10.jpg]](https://www.hovatek.com/blog/bpyeki/uploads/2018/12/How-to-use-Miracle-Box-to-flash-a-single-partition-to-Qualcomm-10.jpg)
- Wait while Miracle box flashes the file
![[Image: How-to-use-Miracle-Box-to-flash-a-single...omm-11.jpg]](https://www.hovatek.com/blog/bpyeki/uploads/2018/12/How-to-use-Miracle-Box-to-flash-a-single-partition-to-Qualcomm-11.jpg)
- You should see Process Done once completed
![[Image: How-to-use-Miracle-Box-to-flash-a-single...omm-12.jpg]](https://www.hovatek.com/blog/bpyeki/uploads/2018/12/How-to-use-Miracle-Box-to-flash-a-single-partition-to-Qualcomm-12.jpg)
Important Notice
- Its important you select the partition that corresponds to the file you're flashing to avoid bricking your device
- If the tool's programmer file (firehose file) isn't working and you have a confirmed working one then untick Auto Programmer and manually load yours
- Its always a good idea to backup your Qualcomm firmware first in case something goes wrong
- This guide isn't guaranteed to work on all Qualcomm devices
- If you run into a "file doesn't exist" error then ensure there's no space in any folder name (in the file path)
Video Transcript
Quote:In this video tutorial, I'll be explaining how to flash a single file or to a single partition on a Qualcomm Android device using Miracle box. First off, you need to have Miracle box. You also need to have the file you intend to flash. I'll be using recovery image in this tutorial. You also need to know how to boot your device into EDL mode. You need to have installed your Qualcomm USB drivers, we have a guide for all of these.
Now, once you've done done this, you launch Miracle box and wait for the dashboard to come up Good! Now, once Miracle box comes up, click on Qualcomm, Flashing you click on Custom Flasher. Now, you boot the device into EDL mode then you connect it to the PC via a USB cord. Once you've done that, click on Port and the device should get detected as Qualcomm HS-USB QDLoader.
Once you've done this, you come back to this part and then you click on File to Write. You select the file you intend to write. I'm writing recovery and you click on Open. Under select partition, you select the corresponding partition which is recovery then you tick Write Partition and click Start Button then wait while the tool writes the image to the device. Alright! I have Process Done.
So that's how to flash to a single partition on a Qualcomm android device using Miracle box
