Qualcomm Device infinix X623 dead flash
Qualcomm Device infinix X623 dead flash
23-06-2025, 09:39 AM
I flashed my infinix X623 with flash file somehow it worked at first with few icon and swipe down not working
I tried with another firmware and now the phone is dead with no sign of on or off but shows port connected on QFIL flash tool, when I tried to flash it says I should switch to EDL mode, when I use the button combinations it doesn't work and when I tried board pinout it doesn't work either
Greatest engineers your help is needed
23-06-2025, 09:51 AM
I tried again with another flash file this time the phone went dead but still shows on QFIL tool that the device is connected
Now I can't switch to EDL mode making it impossible to be flashed
Help needed from all great engineers in the house
Thank you
26-06-2025, 11:52 AM
(23-06-2025, 09:39 AM)dlikedoves I flashed my infinix X623..
Greatest engineers your help is needed
What appears in device manager when you connect the phone to PC?
Learn MediaTek, Unisoc / Spreadtrum (SPD) and Qualcomm Software Repairs @ https://www.hovatek.com/training
Note!
We have a reply schedule for Forum Support. Please try Private Support if you can't wait.
26-06-2025, 01:26 PM
Thank you
03-07-2025, 02:22 PM
(26-06-2025, 01:26 PM)dlikedoves When I select port on the QFIL flash tool I see this: Qualcomm HS-USB Diagnostic 900E (COM45)
Thank you
That is Diag mode.
Was this the pinout you used (image attached below)?
You can also try holding Power + Volume decrease button for about 30 seconds, then retry EDL with button combo
Attached Files
Learn MediaTek, Unisoc / Spreadtrum (SPD) and Qualcomm Software Repairs @ https://www.hovatek.com/training
Note!
We have a reply schedule for Forum Support. Please try Private Support if you can't wait.
03-07-2025, 02:27 PM
It was at the point of trying to buy another panel that the camera prevented the new panel from displaying so I powered mine without the cameras and it worked fine
Thanks once again
